Battery Impendence
In stock

Kikusui Battery Impedance Meter BIM1030

SKU : BIM1030
MAKE : KIKUSUI
MODEL : BIM1030
WARRANTY : 1 Year
AVAILABILITY : IN STOCK
Kikusui

Kikusui Battery Impedance Meter BIM1030

The Kikusui BIM1030 Series is a battery impedance meter used to measure the voltage and internal resistance of batteries quickly and accurately.
It helps determine the health, quality, and performance of battery cells and packs without discharging them.

Features:

  • Measures voltage and internal resistance simultaneously.
  • High accuracy: Voltage ±0.01 %, Resistance ±0.5 %.
  • Fast testing: 20 ms sampling for production or inspection lines.
  • Wide voltage range: Up to 300 V (BIM1030) or 1000 V (BIM1100).
  • Four-terminal method ensures precise low-resistance measurement.
  • Zero adjustment reduces cable/contact errors.
  • Data logging (500 readings) with USB / RS-232 / I/O interfaces.
  • 1 kHz test frequency – standard for battery impedance testing.
  • Color LCD display for easy visibility and operation.

Maximum Measured Voltage

± 300 V

Voltage Measurement Accuracy

±(0.01 % of reading + 3 digits)

Resistance Measurement Accuracy

±(0.5 % of reading + 5 digits)

Resistance Measurement Ranges

3 mΩ / 30 mΩ / 300 mΩ / 3 Ω

Resolution (Best Ranges)

Voltage: 10 µV (6 V range)
Resistance: 0.1 µΩ (3 mΩ range)

Test Frequency

1 kHz ± 0.2 Hz

Sampling Speed (FAST mode)

20 ms (voltage & resistance measured simultaneously)

Memory / Data Logging

Store up to 500 pairs of measurements; USB/RS-232/SIGNAL I/O interfaces standard

Operating Environment

0 °C to 40 °C, Humidity 20%–80% RH (non-condensing)

Dimensions / Weight

Approx. 214 × 80 × 300 mm; ~3 kg

Data-Sheets : Download

1. What is the Kikusui BIM1030 used for?

It is used to measure a battery’s voltage and internal resistance (impedance) to evaluate its health, performance, and quality without discharging the battery.

2. What is the maximum voltage range of the BIM1030?

The BIM1030 can safely measure batteries up to 300 volts, making it ideal for medium-voltage battery modules and packs.

3. Why is internal resistance measurement important?

A high internal resistance indicates a weak or aging battery. The BIM1030 detects this early, helping prevent failures in UPS, solar, or EV systems.

4. How fast does the BIM1030 take measurements?

It performs a complete voltage and resistance test in just 20 milliseconds, enabling fast, efficient testing on production lines or during maintenance checks.

5. Can I store and transfer measurement data?

Yes. The BIM1030 can store up to 500 measurements and transfer data via USB, RS-232, or SIGNAL I/O, making record-keeping and analysis easy.

6. Where is the BIM1030 typically used?

It’s widely used in battery manufacturing, R&D laboratories, and maintenance of UPS systems, solar batteries, and electric vehicles (EVs).

Kikusui Battery Impedance Meter BIM1030

The Kikusui BIM1030 Series is a battery impedance meter used to measure the voltage and internal resistance of batteries quickly and accurately.
It helps determine the health, quality, and performance of battery cells and packs without discharging them.

Features:

  • Measures voltage and internal resistance simultaneously.
  • High accuracy: Voltage ±0.01 %, Resistance ±0.5 %.
  • Fast testing: 20 ms sampling for production or inspection lines.
  • Wide voltage range: Up to 300 V (BIM1030) or 1000 V (BIM1100).
  • Four-terminal method ensures precise low-resistance measurement.
  • Zero adjustment reduces cable/contact errors.
  • Data logging (500 readings) with USB / RS-232 / I/O interfaces.
  • 1 kHz test frequency – standard for battery impedance testing.
  • Color LCD display for easy visibility and operation.

Maximum Measured Voltage

± 300 V

Voltage Measurement Accuracy

±(0.01 % of reading + 3 digits)

Resistance Measurement Accuracy

±(0.5 % of reading + 5 digits)

Resistance Measurement Ranges

3 mΩ / 30 mΩ / 300 mΩ / 3 Ω

Resolution (Best Ranges)

Voltage: 10 µV (6 V range)
Resistance: 0.1 µΩ (3 mΩ range)

Test Frequency

1 kHz ± 0.2 Hz

Sampling Speed (FAST mode)

20 ms (voltage & resistance measured simultaneously)

Memory / Data Logging

Store up to 500 pairs of measurements; USB/RS-232/SIGNAL I/O interfaces standard

Operating Environment

0 °C to 40 °C, Humidity 20%–80% RH (non-condensing)

Dimensions / Weight

Approx. 214 × 80 × 300 mm; ~3 kg

Data-Sheets : Download

1. What is the Kikusui BIM1030 used for?

It is used to measure a battery’s voltage and internal resistance (impedance) to evaluate its health, performance, and quality without discharging the battery.

2. What is the maximum voltage range of the BIM1030?

The BIM1030 can safely measure batteries up to 300 volts, making it ideal for medium-voltage battery modules and packs.

3. Why is internal resistance measurement important?

A high internal resistance indicates a weak or aging battery. The BIM1030 detects this early, helping prevent failures in UPS, solar, or EV systems.

4. How fast does the BIM1030 take measurements?

It performs a complete voltage and resistance test in just 20 milliseconds, enabling fast, efficient testing on production lines or during maintenance checks.

5. Can I store and transfer measurement data?

Yes. The BIM1030 can store up to 500 measurements and transfer data via USB, RS-232, or SIGNAL I/O, making record-keeping and analysis easy.

6. Where is the BIM1030 typically used?

It’s widely used in battery manufacturing, R&D laboratories, and maintenance of UPS systems, solar batteries, and electric vehicles (EVs).
