Klauke Battery Powered Hydraulic Crimping Tool EK120/32

Klauke Battery Powered Hydraulic Crimping Tool EK120/32

SKU : KLK-EK12032
MAKE : KLAUKE
MODEL : EK 120/32
WARRANTY : 1 Year
Klauke

Klauke Battery Powered Hydraulic Crimping Tool EK120/32

The Klauke EK 120/32 is a battery-powered hydraulic crimping tool designed for reliable crimping of cables from 16 to 400 mm². It delivers 120 kN crimping force with a 32 mm stroke, ensuring strong and precise connections. The tool features a rotatable open head, LED work light, automatic retraction, and Bluetooth connectivity via the Klauke Link® App. Powered by an 18 V Li-ion battery (Bosch or Makita), it offers fast, safe, and effortless operation—ideal for professional electrical and industrial applications.

Features:

  • Crimping range: 16–400 mm²
  • Force: 120 kN
  • Open, rotatable head
  • 2-stage hydraulic system
  • Automatic retraction & ARS
  • 18 V Li-ion battery (Bosch / Makita)
  • LED work light
  • One-button operation
  • Bluetooth via Klauke Link® App
  • Visual / audible error signals

Model

Klauke EK 120/32

Type

Battery-powered hydraulic crimping tool

Crimping Range

16 – 400 mm²

Crimping Force

120 kN

Stroke / Opening Width

32 mm

Head Type

Open, rotatable head

Hydraulic System

2-stage (fast feed and power stroke)

Crimping Cycle

7 – 8 s (depending on cable size)

Battery Voltage

18 V Li-ion

Battery Capacity

Bosch – 5.0 Ah / Makita – 4.0 Ah

Charging Time

Bosch – 45 min / Makita – 36 min

Weight (including battery)

6.8 kg

Operating Temperature

–10 °C to +40 °C

Operation

One-button control

Features

Automatic retraction, ARS (Automatic Retract Stop), LED work light, Bluetooth via Klauke Link® App, visual & audible error signals, battery status display

Compatible Dies

13-series interchangeable crimping dies

Applications

Electrical installations, switchgear, power distribution, and industrial cabling

Manufacturer

Klauke (Germany)

Data-Sheets : Download

1. What is the crimping range of the Klauke EK 120/32?

It can crimp cable lugs and connectors from 16 mm² to 400 mm², suitable for medium and large electrical cables.

2. How much crimping force does the tool provide?

The EK 120/32 delivers a powerful 120 kN crimping force for precise and durable connections.

3. What type of head does it have?

It features an open, rotatable head for easy access and quick die changes in tight spaces.

4. What kind of battery does it use?

It operates on an 18 V Li-ion battery, compatible with both Bosch and Makita systems.

5. Does it have smart or safety features?

Yes. It includes automatic retraction, ARS (Automatic Retract Stop), LED work light, and Bluetooth connectivity via the Klauke Link® App for real-time monitoring.

6. What are the main applications of this tool?

It is ideal for electrical installations, switchgear, power distribution, and industrial cabling, offering reliable and efficient crimping performance.

Klauke Battery Powered Hydraulic Crimping Tool EK120/32

The Klauke EK 120/32 is a battery-powered hydraulic crimping tool designed for reliable crimping of cables from 16 to 400 mm². It delivers 120 kN crimping force with a 32 mm stroke, ensuring strong and precise connections. The tool features a rotatable open head, LED work light, automatic retraction, and Bluetooth connectivity via the Klauke Link® App. Powered by an 18 V Li-ion battery (Bosch or Makita), it offers fast, safe, and effortless operation—ideal for professional electrical and industrial applications.

Features:

  • Crimping range: 16–400 mm²
  • Force: 120 kN
  • Open, rotatable head
  • 2-stage hydraulic system
  • Automatic retraction & ARS
  • 18 V Li-ion battery (Bosch / Makita)
  • LED work light
  • One-button operation
  • Bluetooth via Klauke Link® App
  • Visual / audible error signals

Model

Klauke EK 120/32

Type

Battery-powered hydraulic crimping tool

Crimping Range

16 – 400 mm²

Crimping Force

120 kN

Stroke / Opening Width

32 mm

Head Type

Open, rotatable head

Hydraulic System

2-stage (fast feed and power stroke)

Crimping Cycle

7 – 8 s (depending on cable size)

Battery Voltage

18 V Li-ion

Battery Capacity

Bosch – 5.0 Ah / Makita – 4.0 Ah

Charging Time

Bosch – 45 min / Makita – 36 min

Weight (including battery)

6.8 kg

Operating Temperature

–10 °C to +40 °C

Operation

One-button control

Features

Automatic retraction, ARS (Automatic Retract Stop), LED work light, Bluetooth via Klauke Link® App, visual & audible error signals, battery status display

Compatible Dies

13-series interchangeable crimping dies

Applications

Electrical installations, switchgear, power distribution, and industrial cabling

Manufacturer

Klauke (Germany)

Data-Sheets : Download

1. What is the crimping range of the Klauke EK 120/32?

It can crimp cable lugs and connectors from 16 mm² to 400 mm², suitable for medium and large electrical cables.

2. How much crimping force does the tool provide?

The EK 120/32 delivers a powerful 120 kN crimping force for precise and durable connections.

3. What type of head does it have?

It features an open, rotatable head for easy access and quick die changes in tight spaces.

4. What kind of battery does it use?

It operates on an 18 V Li-ion battery, compatible with both Bosch and Makita systems.

5. Does it have smart or safety features?

Yes. It includes automatic retraction, ARS (Automatic Retract Stop), LED work light, and Bluetooth connectivity via the Klauke Link® App for real-time monitoring.

6. What are the main applications of this tool?

It is ideal for electrical installations, switchgear, power distribution, and industrial cabling, offering reliable and efficient crimping performance.
