Klauke EKSD50ML Stripping Tool

Klauke EKSD50ML Electromechanical Stripping Tool – 6–35 mm²

SKU : KLEKSD50ML
MAKE : KLAUKE
MODEL : EKSD50ML
WARRANTY : 1 Year
Klauke
AED 3,800.00 - AED 3,800.00
AED 3,800.00
AED 3,800.00 - AED 3,800.00
AED 3,800.00
(Including VAT)

Klauke EKSD50ML Electromechanical Stripping Tool – 6–35 mm²

The Klauke EK SD 50 ML is a compact and powerful electromechanical stripping tool designed for fast and effortless removal of insulation from various types of conductors. With a 6–35 mm² stripping range, PowerSense technology, and interchangeable stripping inserts, it provides precise and consistent stripping performance for professional electrical applications.

Features:

  • Stripping range: 6–35 mm²
  • Stripping length: Up to 28 mm
  • Cutting capacity: Up to 11.5 mm diameter
  • PowerSense function for easy and controlled operation
  • Suitable for multiple conductor and insulation types
  • One-button operation for simple and safe control
  • Fast and effortless stripping and cutting
  • Electronic control with locking function monitors die closure
  • Ergonomic 2C housing for comfortable handling
  • Lightweight design for efficient operation
  • 10.8 V Li-ion battery with charge status display
  • LED work light for improved visibility
  • Maintenance indication via LED
  • Compatible with 50-series interchangeable dies/inserts
  • Supports single-stranded, multi-stranded, fine-stranded and ultra-fine-stranded round conductors
  • Supplied with battery, charger, stripping inserts, cable stop and plastic case

Model

Klauke EK SD 50 ML

Tool Type

Electromechanical Stripping Tool

Stripping Range

6–35 mm²

Stripping Length

Up to 28 mm

Cutting Range

Up to 11.5 mm diameter

Battery Voltage

10.8 V

Battery Capacity

2.5 Ah, Li-ion

Charging Time

Approx. 45 minutes

Weight incl. Battery

0.96 kg

Ambient Temperature

-10 °C to +40 °C

Conductor Types

Single-, multi-, fine- and ultra-fine-stranded round conductors

Compatible Inserts

50-Series interchangeable stripping inserts

Work Light

LED

Battery Status

Charge status display

Carrying Case

Plastic case

EKSD50ML-Datasheet : Download

1. What is the Klauke EK SD 50 ML used for?

It is designed for fast and effortless stripping of cable insulation from various conductor types.

2. What is the stripping range?

The tool has a stripping range of 6–35 mm².

3. What is the maximum stripping length?

It can strip insulation up to 28 mm in length.

4. What is the maximum cutting capacity?

The tool can cut conductors up to 11.5 mm in diameter.

5. What type of battery does it use?

It operates with a 10.8 V, 2.5 Ah Li-ion battery, with an approximate charging time of 45 minutes.

6. Which conductor types are supported?

It supports single-stranded, multi-stranded, fine-stranded, and ultra-fine-stranded round conductors.
